Where a semiconductor thin film is formed using a conventional precursor solution, the thin film may crack due to the emission of gas created by the intermolecular bonding or solvent during the heat treatment. However, the organic semiconductor thin film of example embodiments may be polymerized through the radical reaction using the increased reactivity of the active mechanism of enediyne, thereby preventing or retarding the thin film from cracking, which may occur due to the generation of gas during a continuous process.

The crosslinking reaction may progress without the use of an additive, thus preventing or reducing the negative effect of interrupting the molecular arrangement due to the use of the additive, which acts as an impurity. In addition, example embodiments provide an electronic device, comprising the organic semiconductor thin film as a carrier transport layer.

The organic semiconductor thin film thus formed may maintain improved transistor properties due to intermolecular packing based on the regular arrangement of a monomolecular aromatic enediyne derivative and intermolecular cross-network formation, and may also assure chemical and electrical stability and reliability upon formation into a polymeric thin film.

Where the organic semiconductor thin film is applied as the carrier transport layer to electronic devices, improved properties may be provided and the cost reduction effect may be maximized or increased by realizing a solution process at about room temperature. The aromatic enediyne derivative of example embodiments may be applied to the above devices using a conventional process known in the art.

A better understanding of example embodiments may be obtained in light of the following examples which are set forth to illustrate, but are not to be construed to limit example embodiments. About 1 equivalent of dialdehyde and about 0. After being allowed to stand overnight, the precipitate was filtered and dried.

About 3 equivalents of trimethylsilyl acetylene, about 0. The tetraethynyl compound in THF was slowly added with a Grignard reagent made using about 3 equivalents of trimethylsilyl acetylene, and then refluxed for about 3 hours. Aqueous SnCl 2 was added to the reactor, and then stirred at about room temperature for about 1 hour. The resultant organic layer was washed with water and chloroform, dried, and then purified through silica column chromatography, thus yielding product 1.

The resultant reaction product was washed with water, and the organic layer was dried and then purified via silica column chromatography, thus yielding a compound 2. Before being coated with the organic semiconductor material, the substrate was washed using isopropyl alcohol for about 10 min and then dried.

The sample was dipped into a about 10 mM octadecyltrichlorosilane solution in hexane for about 30 sec, washed with acetone, and then dried. Thereafter, the aromatic enediyne derivative of Preparative Example 1 was dissolved to about 0. The results are shown in FIG. As shown in FIG. As is apparent from these results, the aromatic enediyne derivative of example embodiments may be formed into a semiconductor thin film through a low-temperature wet process.

As seen in FIG. Therefore, where the semiconductor thin film was formed using the aromatic enediyne derivative of example embodiments, the problem of cracking of the thin film attributable to the generation of gas may be prevented or reduced. In order to evaluate the electrical properties of the OTFTs fabricated in Examples 1 and 2, the current transfer properties thereof were measured using a semiconductor characterization system SCS , available from KEITHLEY, and then charge mobility and cut-off leakage current were calculated.

The results are given in Table 1 below. The charge mobility was calculated from the following current equation for the saturation region using the current transfer curve. Therefore, when applied to various electronic devices, e. As described hereinbefore, example embodiments may provide an aromatic enediyne derivative, an organic semiconductor thin film using the same, and an electronic device using the organic semiconductor thin film. The aromatic enediyne derivative of example embodiments, which is a low-molecular-weight organic semiconductor material having a structure, may be applied using a wet process at about room temperature and may be applicable to the processing of semiconductors having relatively large area.

A chemically and electrically stable and reliable semiconductor thin film that has a regular molecular arrangement and does not crack may be provided. The organic semiconductor thin film of example embodiments may be effectively used in various fields, including OTFTs, EL devices, solar cells, and memory. Although example embodiments have been disclosed for illustrative purposes, those skilled in the art will appreciate that various modifications, additions and substitutions are possible, without departing from the scope and spirit of example embodiments as disclosed in the accompanying claims.

Year of fee payment : 4. Disclosed are a novel aromatic enediyne derivative, an organic semiconductor thin film using the same, and an electronic device. Example embodiments pertain to an aromatic enediyne derivative which enables the formation of a chemically and electrically stable and reliable semiconductor thin film using a solution process, e. A thin film having a relatively large area may be formed through a solution process, therefore simplifying the manufacturing process and decreasing the manufacturing cost. Moreover, it is possible to provide an organic semiconductor that may be effectively applied to various fields including organic thin film transistors, electroluminescent devices, solar cells, and memory.

Field Example embodiments relate to an aromatic enediyne derivative, an organic semiconductor thin film, an electronic device and methods of manufacturing the same. Description of the Related Art In general, flat display devices, e. SUMMARY Accordingly, example embodiments have been made keeping in mind the above problems occurring in the related art, and example embodiments provide an aromatic enediyne derivative, which enables the preparation of a chemically and electrically stable and reliable organic semiconductor through a solution process, e.

An aromatic enediyne derivative, which is represented by Formula 3 below:. Ar is selected from the group consisting of a substituted or unsubstituted C 2 -C 30 fused arylene group and a substituted or unsubstituted C 2 -C 30 fused heteroarylene group, and is condensed with acetylene-substituted rings on both sides thereof.

The enediyne derivative as set forth in claim 1 , wherein the Ar is selected from a group consisting of Formula 4 below, and is condensed with acetylene-substituted rings on both sides thereof:. An organic semiconductor thin film comprising the aromatic enediyne derivative of claim 1. An electronic device, comprising the organic semiconductor thin film of claim 3 as a carrier transport layer.

The electronic device as set forth in claim 4 , wherein the electronic device is a thin film transistor, an electroluminescent device, a solar cell, or memory. A method of manufacturing an organic semiconductor thin film, comprising: i applying a precursor solution, including an aromatic enediyne derivative represented by Formula 3 below:. Ar is selected from the group consisting of a substituted or unsubstituted C 2 -C 30 fused arylene group and a substituted or unsubstituted C 2 -C 30 fused heteroarylene group, and is condensed with acetylene-substituted rings on both sides thereof, and an organic solvent, on a substrate to thus form a coating film; and.

The method as set forth in claim 6 , wherein the precursor solution is prepared by mixing two or more aromatic enediyne derivatives represented by Formula 3. The method as set forth in claim 6 , wherein the aromatic enediyne derivative is included in the precursor solution in an amount of about 0.

The method as set forth in claim 6 , wherein the organic solvent is at least one selected from the group consisting of an aliphatic hydrocarbon solvent, including hexane or heptane, an aromatic hydrocarbon solvent, including toluene, pyridine, quinoline, anisol, mesitylene, xylene or chlorobenzene, a ketone-based solvent, including methyl isobutyl ketone, 1-methylpyrrolidinone, cyclohexanone or acetone, an ether-based solvent, including tetrahydrofuran or isopropyl ether, an acetate-based solvent, including ethyl acetate, butyl acetate or propyleneglycol methyl ether acetate, an alcohol-based solvent, including isopropyl alcohol or butyl alcohol, an amide-based solvent, including dimethylacetamide or dimethylformamide, a halogen-based solvent, including dichloromethane or trichloromethane, a silicon-based solvent, and mixtures thereof.

The method as set forth in claim 6 , wherein applying the precursor solution is performed using spin coating, dip coating, roll coating, screen coating, spray coating, spin casting, flow coating, screen printing, ink jetting, or drop casting. A method of manufacturing an electronic device comprising: manufacturing the organic semiconductor thin film according to claim 6. The method as set forth in claim 12 , wherein the organic semiconductor thin film is a carrier transport layer.
